5030A small size X ray baggage scanners for hand bags security checking

5030A small size X ray baggage scanners for hand bags security checking



1. Technical data

Tunnel size: 505(W)x305(H) mm

Conveyor speed:0.16m/s

Single inspection dosage: <0.1mr

Wire resolution: 0.1mm metal line

Steel penetration: 5mm amor plate

Film safety: for ISO 1600

Maxmum leakage radiation: <0.1mr/H



2. X-Ray generator

Orientation: vertically upward

Tube current: 0.4-0.5MA(adjustable)

Anode voltage: 80KV(adjustable)

Angle: 60 degree

Generator cooling/working periods, sealed oil bath with forced air/100%



3. Image performance system

X-ray sensor: 1 Type photo-diode array detector, 120bit

Monitor: High resolution 17inch color led display

Color quality: 24 bit real colors

Edge enhancement: object contour edge is more distinct

Super image enhancement: image detail is more distinct

High penetrate strength display: increase brightness of dark area in image to diplay object which is behind high absorption mass distinctly

Low penetrate strength display: increase brightness of image/decrease brightness of image

Image recurrence: display previous twenty images and process any one of them

Image restoration: restore image to initial status at the time of stopping conveyor

Image storing: real time store any image and process it in operation status



4. Multi-energy function

Multi-energy color: display organic material for orange, display inorganic material for blue, and display mixture for green

High enery/low energy: switch to display tow energy type, high energy stands for metal etc, low energy stands for non metallic

Auxilitay function for drugs &explosives: help to detect such dangerous material as drugs&explosives ect

Audible&visible alarm: give sound and visible signal when confirming to condition



5. Operating environment

Storage temperature: -20°C to 60°C

Operating temperature:0 °C to 45 °C

Relative humidity: 20 to 95% non-condensing

System power:220VAC (±10%) 50±3HZ

Power wastage: 1.0KW(max)

Noise: <65DB



1)Shipping:3-7days after payment.

2)Package: Wooden case;

285*146*208CM; 8.65488;

125*71*145CM; 1.286875CBM;

Total:1540KGS 9.94cbm;

Wooden case:210Kg;

Net Weight:1330Kg;
